EMT Conduit Pipe ANSI C80.3 Pre-galvanized tube Supplier

Model	ANSI C80.3
Certification	UL
Material	Q195, Q215, Q235, Q345
Trade Size	1/2″ – 4″ ( DN16 – DN103)
Surface	Pre-galvanized
Usage	Exposed and concealed work, lighting circuits, etc

Model

ANSI C80.3

Certification

Material

Q195, Q215, Q235, Q345

Trade Size

1/2″ – 4″ ( DN16 – DN103)

Surface

Pre-galvanized

Usage

Exposed and concealed work, lighting circuits, etc

ANSI C80.3 Standard Pre-Galvanized Steel Conduit EMT Pipe

EMT is manufactured from high-strength steel coil, and produced according to the standard of ANSI C80.3(UL797). The interior surface of ourconduit is free from defect with a smooth welded seam. It is pre-galvanized, hot dipped galvanized inside and outside, so that metal-to-metal contact and galvanic protection against corrosion are provided, and the surface of the conduit is coated with a clear lacquer coating to inhibit white rust and increase corrosion resistance. The interior surface provides a smooth continuous raceway for easy wire pulling. Our EMT conduit has excellent ductility,providing for uniform bending and cutting.

NOTE:
EMT IMC Rigid Conduit with UL listed should be Hot dip galvanized,all Pre-galvanized or Electro-galvanized Pipes can’t pass UL testing pls note.

EMT IMC Pipe bending should be standard thickness
If the thinner type Pipe bending will be wrinkled or broken.

EMT Fittings

EMT conduit comes in a variety of sizes to fill your conduit needs. Remember to include the accessories that you may need to complete the project. This may include threaded 45- and 90-degree fittings, couplings, locknuts, and bushings (regular or self-sealing type).

Example Size

Note: Some of the main specifications are shown below, please contact us for more details.

Trade Size Designator		Nominal Outside Dia.		Nominal Wall Thickness		Two Length
U.S.	Metric	in.	mm	in.	mm	mm	mm
1/2″	16	0.706	17.93	0.042	1.07	3000	3050
3/4″	21	0.922	23.42	0.049	1.24	3000	3050
1″	27	1.163	29.54	0.057	1.45	3000	3050
1 1/4″	35	1.51	38.35	0.065	1.65	3000	3050
1 1/2″	41	1.74	44.2	0.065	1.65	3000	3050
2″	53	2.197	55.8	0.065	1.65	3000	3050
2 1/2″	63	2.875	73.03	0.072	1.83	3000	3050
3″	78	3.5	88.9	0.072	1.83	3000	3050
3 1/2″	91	4	101.6	0.083	2.11	3000	3050
4″	103	4.5	114.3	0.083	2.11	3000	3050
