ASTM A213 Stainless Steel Pipes
ASTM A213 /A213M ASME SA213 covers seamless ferritic and austenitic steel boiler, superheater, and heat-exchanger tubes.
General use A213/SA213 alloy tubing grades are T5, T9, T11, T12, T22, T91, stainless tubing are Grades TP304, TP304L, TP304H, TP309S, TP309H, TP310S, TP310H, TP316, TP316L, TP316H, TP317, TP317L, TP321, TP321H, TP347, TP347H, TP348, TP348H, TP444…
The size range for this tube is from internal diameter 1/8 inch and up to 5 inch OD. Thickness from 0.015 to 0.500 inch (0.4 mm to 12.7 mm). Also if for other size required, it could be specified in the order, also should be stated with minimum and average thickness.
Available size
Note: Some of the main specifications are shown below, please contact us for more details.
DN | NPS | OD (mm) | Wall Thickness | |||||||
Sch 5 | Sch10 | Sch 40 | STD | Sch 80 | XS | Schl60 | XXS | |||
8 | 1/4″ | 13.7 | – | 1.65 | 2.24 | 2.24 | 3.02 | 3.02 | – | – |
10 | 3/8″ | 17.1 | – | 1.65 | 2.31 | 2.31 | 3.20 | 3.20 | – | – |
15 | 1/2″ | 21.3 | 1.65 | 2.11 | 2.77 | 2.77 | 3.73 | 3.73 | 4.78 | 7.47 |
20 | 3/4″ | 26.7 | 1.65 | 2.11 | 2.87 | 2.87 | 3.91 | 3.91 | 5.56 | 7.82 |
25 | 1″ | 33.4 | 1.65 | 2.77 | 3.38 | 3.38 | 4.55 | 4.55 | 6.35 | 9.09 |
100 | 4″ | 114.3 | 2.11 | 3.05 | 6.02 | 6.02 | 8.56 | 8.56 | 13.49 | 17.12 |
One-stop service to facilitate your purchase
The Lai Group continues to provide service and support after your purchase. To save you time, we offer you numerous value-added services such as processing, logistics management and testing.
Processing Services:
- OEM & ODM
- Protective Coatings
- Saw and Flame Cutting
- Beveling, Threading and Grooving
For more information, please contact our service team.
